Серия FP3000: особенности
DVI I/F Supported
The featured DVI, clearing graphic images, offers improved visual clarity and operability. Equipped USB interface which can be connected directly to the peripheral devices.
Durable even in harsh environments
Pro-face creates environmental resistance equivalent to IP65f. The overlay (front sheet) protects the panel from oil mists, water droplets, and/or dust. Furthermore, its superior concussion and high-temperature resistance enable safe use at various sites.
Panel Cut-Out Dimensions
All FP Series models are designed with identical panel cut-out dimensions. This saves you the trouble of changing the mounting holes when attaching a new panel.
- Please check the screen displays properly when replacing.
FP Series - Main Units | |||
Series | Memo | Product | Part Number |
10'' | 10.4" TFT Color VGA, DC24V (CE/UL/c-UL) | FP3500-T41-24V | |
12'' | 12.1" TFT Color SVGA, DC24V (CE/UL/c-UL) | FP3600-T41-24V | |
12.1" TFT Color XGA, AC type (CE/UL/c-UL) | FP3650-T41 | ||
15'' | 15" TFT Color XGA with Keypad, AC type, Front USB (CE/UL/c-UL) | FP3710-K41-U | |
Flat Panel Display, 15" TFT Color XGA, AC100-240V (CE/UL/c-UL) | FP3710-T42 | ||
Flat Panel Display, 15" TFT Color XGA, AC100-240V, Front USB (CE/UL/c-UL) | FP3710-T42-U | ||
15-inch flat panel monitor, 1024x768 (XGA), USB in front, power supply: DC 24V |
FP3710-T42-24V-U | ||
19'" | 19" SXGA flat Panel Display without a front USB and AC (100-240V) power supply (RoHS Directive-conforming product) | FP3900-T41 | |
19" SXGA flat Panel Display with a front USB and AC (100-240V) power supply (RoHS Directive-conforming product) | FP3900-T41-U | ||
UF | 15” TFT XGA Color LCD, DC24V, CE , Open Frame | UF7811-2-DV1-24V | |
FP Series - Option | |||
Series | Memo | Product | Part Number |
Cable | Analog RGB Cable for FP2000/77*/790 and UF Series, 2.5 m | FP-CV00 | |
Analog RGB Cable for FP2000/77*/790, 5 m | FP-CV01 | ||
Analog RGB Cable (4.5m) for FP3000 series/RGB unit | FP-CV02-45 | ||
USB Touch Panel Cable for FP2000/FP3000 series, 5M | FP-US00 | ||
Touch Panel Cable for FP3000/UF Series, 5m | FP61V-IS00-O | ||
DVI Cable (5m) for FP3000 series | FP-DV01-50 | ||
DVI Cable (10m) for FP3650/3710/3900T when used with PS-2000B | FP-DV01-100 | ||
AC power connector for IPC & FP, AC power connector (5 pairs),(RoHS Directive-conforming product) | CA7-ACCNL-01 | ||
Cover | Screen Protection Sheet for FP3500/3600 | PSL-DF00 | |
Screen Protection Sheet for 19-inch, hard type (5 sheets) | CA7-DFS19-01 | ||
Rear Cover for FP36*0/3500 | CA1-RCVLRG-01 | ||
Desktop Stand FP36*0/3500 | CA1-STDLRG-01 | ||
Backlight | Backlight for FP3500 | GP577RT-BL00-MS | |
Backlight for FP3650T | CA5-BLU12XGA-01 | ||
Backlight for FP3710K | CA7-BLU15-01 | ||
Other | Installation Fasteners 4 pairs (RoHS Directive-conforming product) | CA3-ATFALL-01 | |
Installation Gasket for 19-inch(RoHS Directive-conforming product) | CA7-WPG19-01 |
